Are you looking for a high-quality cross-cutting line with outstanding performance?
Tengdi Machinery stands as a premier manufacturer of cross-cutting production lines, inviting collaboration opportunities. Our extensive range of crosscutting machines is meticulously designed to fulfill your unique specifications. Count on us to provide the crosscutting line option that perfectly aligns with your needs. Backed by skilled experts with years of experience, Tengdi ensures the highest standard of workmanship in all our endeavors.
| Cutting Width (mm): | 500 - 2000 mm | Material Thickness(mm): | 3 - 12 mm |
| Cutting Speed(m/min): | 1 - 40 m/min | Coil Weight (T): | 30T |
| Leveling Precision(±mm/m): | 1.5 ±mm/m | Voltage: | 380v |
| Rated Power: | 300KW | Dimension(L*W*H): | 28X8X2m |
| Weight: | 5000 | Coil Thickness: | 2-8mm |
| Coil width: | 800-2000mm | Coil weight: | max 30T |
| Total line power consumption: | 300KW | Total weight: | 50T |
| Line Speed: | 40m/min | Cutting length: | 2000mm-12000mm |
| Core Components: | PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pu | ||
| Type | 3×1600 | 6×2000 | 8×2000 | 10×2200 | 12×2200 | 16×2200 | 20×2500 | 25×2500 |
| Thickness Range(mm) | 0.3-3 | 1-6 | 2-8 | 2-10 | 3-12 | 4-16 | 6-20 | 8-25 |
| Width Range(mm) | 1600 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 |
| Cutting Length(mm) | 300-4000 | 500-6000 | 600-8000 | 600-10000 | 800-12000 | 800-12000 | 800-12000 | 800-12000 |
| Cutting precision(mm) | ±0.5 | ±0.5 | ±1 | ±1 | ±1 | ±1 | ±1 | ±1 |
| Roller Numbers | 15 | 15 | 13 | 13 | 11 | 11 | 9 | 9 |
| Roller Diameter(mm) | Ф85 | Ф140 | Ф155 | Ф160 | Ф180 | Ф200 | Ф230 | Ф260 |
| item | specifications | |
| Raw materials | Materials feature: | HR YS 450 TS 350 |
| thickness: | 2.0mm-8.0mm | |
| width: | 800mm-2000mm | |
| O.D: | Φ1000mm-φ2150mm | |
| I.D: | φ500mm-φ800mm | |
| Coil weight: | Max 30T | |
| Finished product | Cutting length: | 2000mm-12000mm |
| Cutting tolerance: | ±1.5mm( length tolerance) ±2.0mm( diagonal tolerance) Match the standard GB/T709-88 | |
| Leveling speed | 0-40m/min | |
| Max cutting thickness | 12mm | |
| Center line of the line ( to the ground) | 800mm | |
