Advantage:
1. The cutter head has multiple functions of flattening and chamfering, and it can complete flattening and chamfering at the same time.
2. The transmission shaft adopts a sandwich structure, which is installed and positioned precisely, and improves the overall durability of the traverse.
3. Equipped with a loose clamp detection proximity switch to prevent the clamping cylinder from malfunctioning and causing accidents.
4. The parameters of multi-standard steel pipes can be set. When changing the specifications, the operator does not need to reset the parameters every time, just select the specifications.
5. The feed ball screw adopts Taiwan Shangyin 63-10, which is durable.
Key Selling Points: | Easy to Operate | Weight (KG): | 300 KG |
Certification: | CE | Type: | Double Heads Chamfering |
After-sales Service Provided: | Field installation, commissioning and training, Field maintenance and re |
Steel pipe outside diameter | Φ17.1~Φ60.3mm |
Steel pipe length | 6~12.5 m |
Steel pipe wall thickness | 2-12.7mm |
Steel pipe straightness | 0.1%L |
Steel pipe ellipticity | 1.0%D(max) |
Steel pipe outside diameter deviation | ±1mm |
Condition of the end face of the steel pipe | The inner and outer circles are flat within 150mm of the pipe end, and the positive deviation is not more than 0.5mm |
Pipe end bevel | Determined according to specific process parameters (30°) |
blunt edge size | ≥1.6±0.8 mm |
Pipe end bevel | ≤1.6mm |
chamfering | Single |
Executive standard | API 5L GB/T9711.1 GB/T9711.2 |
Productivity | 60~100 pieces/hour |
The equipment is mainly used for the diameter range in Φ219~Φ406mm straight seam welded steel pipe within the tube end chamfering head.The end facer machine adopts mature and reliable international advanced technology. Product quality, production cost, various consumption indicators and labor productivity meet the requirements of product process and efficiency.
Ambient temperature (indoor) | 5~ +40℃ |
Environment humidity | ≤90% |
Supply voltage | 380V ±10%(TN-C-S system) |
Frequency | 50 Hz ±1% |
Control voltage | 220 VAC / 24 VDC |
Compressed air | 0.4~0.6Mpa |
Noise when the equipment is working | <85dB |
Cooling water pressure | 0.3-0.6MPa (T.O.P) |
Compressed air | 0.4~0.6Mpa |
Noise when the equipment is working | <85dB |
Cooling water pressure | 0.3-0.6MPa (T.O.P) |
Cooling water PH value | 7-8 |
Cooling water suspension | 50-100 mg/L |
Cooling water hardness | 7-110dH |
Cooling water particle | Max. 0.06 mm |
Cooling water sulfate content | <400 mg/L |
