Cgl Continuous Galvanizing Line

Brand:Tengdi Machinery
Lead Time:
Est. Time(days) 60
Comprehensive scheme customization of equipment
1 Year warranty

Are you looking for a high-quality hot-dip galvanizing line with excellent performance?

Hot-dip galvanizing is to pickle the steel pipe first. In order to remove the iron oxide on the surface of the steel pipe, after pickling, it is cleaned in a tank of ammonium chloride or zinc chloride aqueous solution or a mixed aqueous solution of ammonium chloride and zinc chloride, and then sent to a hot dip bath. Hot-dip galvanizing has the advantages of uniform coating, strong adhesion and long service life. A complex physical and chemical reaction occurs between the hot-dip galvanized steel pipe substrate and the molten plating solution to form a corrosion-resistant zinc-iron alloy layer with a dense structure.

Steel pipe galvanizing line production line features

1. The fully automatic steel pipe hot-dip galvanizing production line realizes fully automatic pickling in the closed room. While ensuring the pickling efficiency, it realizes automatic replacement of pickling slings, avoids the addition of additive liquid components into the acid tank, and achieves the purpose of cleaning acid.

2. The optimally designed galvanizing line equipment has simpler operation, low noise, high stability and easier maintenance.

3. Realize the automation and informatization of the whole system, which is conducive to the control of production costs and the improvement of product quality.

4. Based on the production process, the layout of the production line is more reasonable.

5. Reasonable selection of production line equipment, energy saving and consumption reduction are more prominent.

Quick Details
Type:                         Coating Production Line                         Substrate:                         Steel
Coating:                         Galvanizing                         Voltage:                         380V/ 440V
Galvanized product:                         Pipe/tube                         Auto type:                         Full-automatic
After-sales Service Provided:                         Engineers available to service machinery overseas


Production process:

(Pipe → pickling → rinse → solvent →) drying → hot-dip galvanizing → lead → lead → translation → blowing → water cooling → pipe passivation → drying → typing → inspection → packaging → finished

Other specifications and industry applications
Item                         Hot Dipped Galvanized Round Steel Pipe/GI Pipe/Galvanised Tube
OD                         20~405mm  in theory
Thickness                         1.2~15.7mm
Length                         Any Length Below 16 Meter
Standard                         GB,ASTM,BS,EN,JIS



ASTM, Grade B,Grade C,Grade D,Grade 50
EN, S185,S235JR,S235JO,E335,S355JR,S355J2
JIS, SS330,SS400,SPFC590
Application                         Used For Water, Gas, Stream, Combustible Fluids And Other Liquid Delivery



Plain, Beveled, Thread With Couplings Or Sockets;
Plastic Caps And Steel Rings Can Be Provided If Possible
Surface                         Bared, Galvanized, Oiled, Color Paint, 3PE; Or Other Anti-corrosive Treatment
Technique                         Hot Rolled Or Cold Rolled ERW
Package                         Covered With Tarpaulin, Containers Or In Bulk
Payment Terms                         TT30% Deposit, balance after BL copy in 21 days, or LC at sight
continuous galvanizing line process
continuous galvanizing
Packaging and delivery

Packaging and delivery

Exhibition photos

Exhibition photos




Q: Are you manufacturer?

A: Yes. We are manufacturer. We have our own technical team. Welcome to visit us.



Q: What payment terms do you accept?

A: We are flexible on payment terms, please contact us for details!



Q: What info you need before you make the proposal?

A: The pipe diameter and thickness range which you need or the profile drawings material information, your special requirements and speed of the machine.



Q: How do you do QA?

A: We have special team do strict QA, this is our strengths:

(1)Every gear box will be tested for 8 hours with oil inside to guarantee there is no leak.

(2)Every shaft will be inspected for the centering jumpiness.

(3)Every roller will be checked to make sure it is in the range of tolerance critical parts will be inspected for all dimensions.



Q: Why choose you? What is the difference between you and other Chinese supplier?

A: You can get higher quality product & better professional service from TENGDI with same price.



Q: What I should do if just start a new business?

A: Contact us immediately, we provide free consultant pre-sales service



Q: How about your service?

A:Our services include:

(1)Warranty is one year, Any parts damaged during warranty will be replaced for free!

(2)We provide spare parts for life time at cost price. Electrical parts such as boards and servo drives, we'll provide them for life time as well at cost price.

(3)We provide Video technical support, Field installation, commissioning and training, online support, Engineers available to service machinery overseas.
