HG219 High Frequency Welding ERW Steel Tube Mill / Erw Tube Mill

Brand:Tengdi Machinery
Model Number:
HG219
Max Pipe Diameter:
102-219mm
Maximum Dhickness:
3.0-10.0mm
Customization:
Comprehensive scheme customization of equipment
Service:
Lifetime maintenance
SKU:
Availability:

Are you looking for high-quality High Frequency Welding ERW Steel Tube Mill that will provide exceptional performance?

Tengdi Machinery is an excellent steel pipe making machine manufacturer with whom to explore collaborating. Tengdi provide a large selection of various steel pipe making machine choices that are intended to meet your unique requirements. We can be sure that you will get the finest steel pipe making line option for your needs. Tengdi collaborate with skilled specialists who contribute their years of experience and guarantee that all of our works meet the highest standards.

Quick Details


Manufacture Tengdi Machinery Name ERW pipe making machine
Type HF Solid state steel pipe welding production line Line speed ≤50m/min
Round pipe dia 102-219mm Round pipe thickness 3.0-10.0mm
Square & rectangular pipe size 80*80-170*170mm Square & rectangular  pipe thickness 3.0-10.0mm
Pipe material Carbon steel/Galvanized steel Place of Origin Shijiazhuang, China
Voltage 220/380/415/440V Forming method

Push square structure;

Roll quick change method

erw pipe mill for sale
erw steel pipe mill
high speed tube mill
IMG_20150914_155335



Other specifications and industry applications


Model Procession
(mm)
Round thickness
(mm)

Square/Rectanglar

(mm)

Pipe thickness

(mm)

Welding speed
(m/min)
High frequency power(kw)
Φ50 Φ19—Φ50 0.6-3.5 15*15-40*40 0.6-3.0 20-120 200
Φ60 Φ21—Φ60 0.8-3.5 15*15-50*50 0.8-3.0 20-120 200
Φ76 Φ21—Φ76 0.8-4.0 15*15-60*60 0.8-3.5 20-110 300
Φ89 Φ32—Φ89 1.0-4.5 25*25-70*70 1.0-4.0 20-100 400
Φ114 Φ48—Φ114 1.5-5.0 35*35-90*90 1.5-4.5 20-70 500
Φ165 Φ89—Φ165 ≤8 70*70-130*130 ≤7 ≤60 600
Φ219 Φ102—Φ219 ≤10 80*80-170*170 ≤9 ≤50 600
Φ273 Φ114—Φ273 ≤14 90*90-200*200
≤12 ≤40 1000
Φ325 Φ127—Φ325 ≤16 100*100-250*250 ≤14 ≤35 1000
Φ406 Φ219—Φ406 ≤16 170*170-300*300
≤14 ≤30 1000
Φ660 Φ325—Φ660 ≤22 250*250-500*500 ≤20 ≤30 1200
微信图片_20230518133727
Flow chart and finished product diagram

001ABF35-2962-4583-977C-1224C0C1023F

high speed tube millHG406

IMG_5927

Packaging and delivery

Tengdi Packaging and delivery

Processing capacity

Tengdi Processing capacity

Exhibition photos

Tengdi Exhibition photos

Certificate

Tengdi Certificate

QFA

Q: Are you manufacturer?

A: Yes. We are manufacturer. We have our own technical team. Welcome to visit us.


Q: What payment terms do you accept?

A: We are flexible on payment terms, please contact us for details!


Q: What info you need before you make the proposal?

A: The pipe diameter and thickness range which you need or the profile drawings material information, your special requirements and speed of the machine.


Q: How do you do QA?

A: We have special team do strict QA, this is our strengths:

(1)Every gear box will be tested for 8 hours with oil inside to guarantee there is no leak.

(2)Every shaft will be inspected for the centering jumpiness.

(3)Every roller will be checked to make sure it is in the range of tolerance critical parts will be inspected for all dimensions.


Q: Why choose you? What is the difference between you and other Chinese supplier?

A: You can get higher quality product & better professional service from TENGDI with same price.


Q: What I should do if just start a new business?

A: Contact us immediately, we provide free consultant pre-sales service


Q: How about your service?

A:Our services include:

(1)Warranty is one year, Any parts damaged during warranty will be replaced for free!

(2)We provide spare parts for life time at cost price. Electrical parts such as boards and servo drives, we'll provide them for life time as well at cost price.

(3)We provide Video technical support, Field installation, commissioning and training, online support, Engineers available to service machinery overseas.
